S16 Solar energiser with battery (0.16J – Solar)

The S16 is the ultimate portable energiser solution, storing 0.16 J and capable of powering up to 1 mile/1,5km or 0.5 hectare of Multi-wire fence. The energiser comes complete with a rechargeable battery and solar panel.

The S16 is quick and easy to install and convenient to transport. This robust and highly portable unit makes a great alternative to battery- powered systems.

The S16 is not suitable to use with netting or the SmartFence.

Specifications:

• Maximum output voltage (V): 6900

• Charging energy (J): 0.16

• Maximum impulse energy (J): 0.13

• Solar panel (Watt): 1.5

• Number of earthing rods required: 1 x 0.5 m

• No vegetation (km) (recommended): 1.5

• Light vegetation (km) (recommended): 0.8

• Dense vegetation (km) (recommended): 0.5

• Fence surface (ha) (recommended): 0.8

• Specifications

  Product number:	341316
  Warranty (years):	3
  IPX classification:	IPX4
  Recommended number of earth stakes:	1×0,5m
  Normal – slow pulse mode:	–
  Auto power conservation to prevent damage to battery:	–
  Device indicator light On/Off:	–
  Battery LED (indicator):	–
  Battery safemode:	✓
  Grid area (Hec/Acre):	0,8/2
  Multi (3) Wire Fence distance – Recommended (km):	0,5
  Multi (2) Wire Fence distance – Ideal conditions (km):	1,5
  Multi (2) Wire Fence distance – Light conditions (km) :	0,8
  Single Wire Fence distance – Ideal conditions (km):	4,5
  Output Energy (J):	0,13
  Stored Energy (J):	0,16
  Voltage with 100 Ohm (V):	500
  Output with 500 Ohm (V):	2000
  Maximum output Voltage:	6900
  Avg. current draw Battery (V/mA):	6/21
  Days operational with no daylight:	^20 days
  Half power mode / Wildlife mode:	-/-
  Night savings option:	✓
  Built-in solar panel:	1,5W
  Fence connection wire included:	✓
  Rechargeable Battery included:	✓
  Recommended Battery (minimal advised):	VRLA 6V-4Ah
  Recommended replacement Battery (Part No.):	075188
  Suitable Stand (height):	007509 (88cm), 730003 (50cm)
  Weight (Kg):	1,9
